ReflecTube® 1592 is a reflective convolute sleeve designed to provide thermal protection for components in radiant heat environments. Composed of a high temperature nylon 4,6 polymer base substrate and a highly reflective coating, ReflecTube 1592 provides protection for wires, cables and hoses in applications that have radiant heat source temperatures as high as +538ºC (+1000ºF).
The reflective surface is extremely resistant to automotive fluids and may be classed as insulative against 12 volt automotive currents. Because of its unique blend of thermal and insulative properties, as well as its aesthetic appearance, it is ideal for applications such as battery cables and alternator wiring harnesses.
Product Highlights
• Operating temperature up to +150°C (+302°F)
• High abrasion resistance
• Additional radiant heat protection
• Highly flexible convoluted design
• Tubular and slit forms
• Fluid resistant
Typical Applications
• Battery cables
• Wiring systems
• Electronic sensor control wiring
• Critical harnesses exposed to radiant heat
Availability
• Standard sizes are listed here. Additional sizes could be available upon request.
• Available in tubular and slit form. Customization for optimal installation also available.
• Available in custom cut lengths. Recommended cut lengths are in 5mm increments.
- Short Product Description:
- ReflecTube® 1592 for radiant heat source temperatures as high as +538ºC (+1000ºF).
- Datasheet Link:
- /content/data_sheets/ReflecTube_1592.pdf
