Shrinkflex® 2:1 Fabric is Heat shrink tubing, a unique mixture of Polyolefin and Polyester yarns which shrinks to ½ its original diameter, is the ideal way to form the only shrinkable fabric of its kind.
The woven construction makes this product extremely flexible and resistant to trapping water, heat and humidity. Provides outstanding abrasion, chafing and cutting protection, even at high temperatures.
Shrinkflex Fabric tubing, designed primarily to provide mechanical abrasion protection for components such as rubber hoses, plastic pipes, and harness wiring bundles. Also suitable for other applications, such as noise and rattle suppression.
Product Highlights
• Minimum and Maximum Continuous temperature -40°C to +135°C (-40°F to 275°F)
• Shrinks at 135°C (275°F)
• Excellent Chemical Resistance
• Highly Flexible
• MECHANICAL ABRASION PROTECTION
• Flammability Rating is Non-Flame Retardant
• Color is Black
| Size | Part Number | Unshrunk Diameter | Shrunk Diameter | Bulk Spool | Shop Spool | LB/ 100' |
|---|---|---|---|---|---|---|
| 1/2" | H2F0.48 | 12mm | 6mm | 100 | 25 | 1.150 |
| 3/4" | H2F0.79 | 20mm | 10mm | 100 | 25 | 1.610 |
| 1-3/16" | H2F1.18 | 30mm | 15mm | 100 | 25 | 2.130 |
| 1-1/2" | H2F1.58 | 40mm | 20mm | 100 | 25 | 2.660 |
| 2" | H2F1.97 | 50mm | 25mm | 100 | 25 | 3.440 |
| 2-3/8" | H2F2.36 | 60mm | 30mm | 100 | 25 | 4.110 |
| 2-3/4" | H2F2.75 | 70mm | 35mm | 100 | 25 | 4.690 |
- Short Description:
- Fabric heatshrink tubing, a unique mixture of polyolefin and polyester yarns, is the ideal way to form the only shrinkable fabric of its kind.
