4:1 Shrinkflex heat shrink tubing is the most versatile of the heat shrink products. The high shrink ratio ensures that the
tubing will slip over large connectors or plugs and still provide a tight, professional seal.
This high shrink ratio tubing shrinks 75% or more in the radial direction and 50% or less in the axial direction. Resistant to abrasion, chemicals, and oils, Shrinkflex tubing will ensure maximum protection while providing neat end terminations.
Product Highlights
• Operating temperature from -55°C to +135ºC (-67ºF to +275ºF)
• Shrinks at 90°C (194°F)
• Melt Point (ASTM D-2117) 200°C (392°F)
• Flammability Rating UL 224, VW-1, and RoHS Compliant
• Low Temperature Flex -55°C (-67°F) (MIL-DTL-23053) No Cracking
• Dielectric Strength (volt/mil) (ASTM D-876) 500
• Volume Resistivity (ohm/cm) (ASTM D-876) 1.0 x 10¹4
• Colors 12
Product Specifications
| Size | Part Number | Unshrunk Diameter | Shrunk Diameter | BULK SPOOL | Shop SPOOL | Lbs / 100' |
|---|---|---|---|---|---|---|
| 1/2" | H4N0.50 | 12.0mm | 3.0mm | 200 | 25 | 1.17 |
| 3/4" | H4N0.75 | 19.0mm | 4.5mm | 100 | 25 | 2.75 |
| 1" | H4N1.00 | 25.4mm | 7.0mm | 100 | 25 | 3.25 |
| 1-1/4" | H4N1.25 | 32.0mm | 8.0mm | 100 | 25 | 4.00 |
| 1-1/2" | H4N1.50 | 38.0mm | 95mm | 100 | 25 | 4.25 |
- Short Product Description:
- Versatile & Economical Termination Solution
