Shrinkflex 2:1 PTFE is a Polytetrafluoroethylene heat shrink tubing has the lowest coefficient of friction of any polymer and possesses a broad temperature range, allowing it to excel equally in extreme cold and hot environments.
PTFE’s excellent dielectric strength makes it highly suited for the encapsulation of wires and electrical components. Also it has has excellent lubricity and chemical resistance.
Product Highlights
• Minimum and Maximum Continuous temperature (Mil-I-23053) -200°C to +260°C (-328°F to 500°F)
• Shrinks at 343°C (650°F)
• Meet Specification MIL-I-DTL-23053/12
• Excellent Dielectric Strength
• Resistant to All Common Solvents, Acids, and Bases
• Flame Resistant
• Color is Clear
*PTFE Heat Shrink is produced dimensionally to the mil-spec but is NOT QPL listed*
Product Specifications
| Size | Part Number | Unshrunk Diameter | Shrunk Diameter | WALL THICKNESS | Put Up/4' Pcs. |
|---|---|---|---|---|---|
| 24 AWG | M23053-12-201-C | 1.27mm | 0.69mm | 0.30mm | 1 |
| 22 AWG | M23053-12-202-C | 1.40mm | 0.81mm | 0.30mm | 1 |
| 20 AWG | M23053-12-203-C | 1.52mm | 0.99mm | 0.41mm | 1 |
| 19 AWG | M23053-12-204-C | 1.65mm | 1.09mm | 0.41mm | 1 |
| 18 AWG | M23053-12-205-C | 1.93mm | 1.24mm | 0.41mm | 1 |
| 17 AWG | M23053-12-206-C | 2.16mm | 1.37mm | 0.41mm | 1 |
| 15AWG | M23053-12-207-C | 2.79mm | 1.70mm | 0.41mm | 1 |
| 14AWG | M23053-12-208-C | 3.05mm | 1.83mm | 0.41mm | 1 |
| 13 AWG | M23053-12-210-C | 3.56mm | 2.03mm | 0.41mm | 1 |
| 12 AWG | M23053-12-211-C | 3.81mm | 2.26mm | 0.41mm | 1 |
| 11 AWG | M23053-12-212-C | 4.32mm |
2.57mm | 0.41mm | 1 |
| 10 AWG | M23053-12-213-C | 4.85mm | 2.84mm | 0.41mm | 1 |
| 9 AWG | M23053-12-214-C | 5.21mm | 3.15mm | 0.51mm | 1 |
| 1/8" | M23053-12-215-C | 5.46mm | 3.30mm | 0.51mm | 1 |
| 8 AWG | M23053-12-216-C | 6.10mm | 3.58mm | 0.51mm | 1 |
| 7 AWG | M23053-12-217-C | 6.86mm | 4.01mm | 0.51mm | 1 |
| 6 AWG | M23053-12-218-C | 7.67mm | 4.52mm | 0.51mm | 1 |
| 5 AWG | M23053-12-219-C | 8.13mm | 5.03mm | 0.51mm | 1 |
| 4 AWG | M23053-12-220-C | 9.40mm | 5.69mm | 0.51mm | 1 |
| 3 AWG | M23053-12-221-C | 9.91mm | 6.32mm | 0.51mm | 1 |
| 1/4" | M23053-12-222-C | 10.41mm | 6.60mm | 0.51mm | 1 |
| 2 AWG | M23053-12-223-C | 10.92mm | 7.06mm | 0.51mm | 1 |
| 1 AWG | M23053-12-224-C | 11.43mm | 7.90mm | 0.51mm | 1 |
| 5/16" | M23053-12-225-C | 11.94mm | 8.36mm | 0.51mm | 1 |
| 0 AWG | M23053-12-226-C | 11.94mm | 8.81mm | 0.51mm | 1 |
| 3/8" | M23053-12-228-C | 14.22mm | 10.13mm | 0.64mm | 1 |
| 7/16" | M23053-12-229-C | 16.64mm | 11.73mm | 0.64mm | 1 |
| 1/2" | M23053-12-230-C | 19.05mm | 13.31mm | 0.64mm | 1 |
| 5/8" | M23053-12-231-C | 23.62mm | 16.64mm | 0.76mm | 1 |
| 3/4" | M23053-12-232-C | 28.58mm | 19.96mm | 0.89mm | 1 |
| 7/8" | M23053-12-233-C | 33.27mm | 23.14mm | 0.89mm | 1 |
| 1" | M23053-12-234-C | 38.10mm | 26.31mm | 0.89mm | 1 |
- Shrinkflex 2:1 PTFE:
- Our PTFE tubing is 100% PFOA free.
